C273001 This product is discontinued This product has been replaced with:LQ-2090 Impact Printer

Specifications

Printing Method

• 24-pin, impact dot matrix, wide carriage

Print Speed (cps @10 cpi)

High Speed Draft

• 400

Draft

• 300

NLQ (9-pin) / LQ (24-pin)

• 100

Maximum Form Parts

• 5

Input Buffer

• 64 KB

MTBF

• 10,000 POH @ 25% duty

Print Head Life

• 200 million strokes/wire

Sound Level

• 54 dB(A)

Standard Interface

• Parallel

Printer Language

• ESC/P2, IBM 2391 Plus emulation (IBM ProPrinter compatible)

Physical Dimensions

Height (inches)

• 10.6"

Width (inches)

• 25.2"

Depth (inches)

• 15.8"

Weight (lbs)

• 28.7 lbs
