Video System

NTSC / PAL (switchable)

Video Compression Format

Frame: MJPEG ; CIF: MPEG4

Video Input

4 Channels. Composite video signal 1 Vp-p 75Ω BNC

Video Loop Out

4 Channels. Composite video signal 1 Vp-p 75Ω BNC

Video Output

Main Monitor Output: Composite video signal 1 Vp-p 75Ω BNC

Call Monitor Output: Composite video signal 1 Vp-p 75Ω BNC

Maximum Recording Rate

Frame: 720×480 pixels with 30 IPS / 720×576 pixels with 25 IPS
CIF: 352×240 pixels with 120 IPS / 352×288 pixels with 100 IPS

Adjustable Recording Speed

Frame: 30, 15, 7, 3 IPS / 25, 12, 6, 3 IPS
CIF: 120, 60, 30, 15 IPS / 100, 50, 25, 12 IPS

Image Quality Setting

Best, High, Normal and Basic

Hard Disk Storage

IDE type, ATA66, supported HDD???1, support HDD capacity over 400GB

HDD Quick Cleaning

Quick clean up the “index system” of the recorded files. 250GB under 2 seconds

Recording Mode

Manual / Timer / Motion / Alarm / Remote

Refresh Rate

120 IPS for NTSC / 100 IPS for PAL

Audio I/O

1 audio input, 1 audio output (Mono)

Motion Detection Area

16 × 12 grids per camera for all channels

Motion Detect Sensitivity

4 adjustable variables with precise calculation for motion detection

Pre-alarm Recording

Yes (8MB)

Backup Device

Network remote backup

Web Transmitting / Compression Format

Motion JPEG

Ethernet

10/100 Base-T. Support remote control and live view via Ethernet.

Web Interface

Support licensed software AP and IE browser

Remote Alarm Notification

E-mail images, and upload images to FTP site’s specific account

Network Connection

Support TCP/IP, PPPoE, DHCP and DDNS function

PTZ control

Support PELCO-D protocol

Dwell Time (Sequential Channel Switch)

Programmable with adjustable dwell time

Alarm I/O

4 inputs, 1 output

Digital Zoom

2X digital zoom (live mode)

Key Lock

Yes

Video Loss Detection

Yes

Camera Title

Support up to 6 letters

Video Adjustable

Hue / Color / Contrast / Brightness

Date Display Format

YY/MM/DD, DD/MM/YY, MM/DD/YY, and Off

Power Source

DC 19V

Power Consumption

???42 W

Operating Temperature

10??? ~ 40??? (50???~104???)

Dimensions (mm)

343mm (W) × 59mm (H) × 223mm (D)

System Recovery

System auto recovery after power reconnected

Optional Peripheral

VGA converter
