FLUKE88V/Automotive-Multimeter

Technical Specifications DCV Maximum voltage 1000 V Accuracy ±(0.1% + 1) Best resolution 0.01 mV ACV Maximum voltage 1000 V Accuracy ±(0.5% + 2) AC bandwidth 5 kHz Best resolution 0.01 mV DC current Maximum amps 10 A Amps accuracy ±(0.4 % + 2) Best resolution 0.001 mA AC current Maximum amps 10 A Amps accuracy ±(1.2% + 2) Best resolution 0.001 mA Resistance Maximum resistance 50 MΩ Accuracy ±(0.4% + 1) Best resolution 0.1 Ω Capacitance Maximum capacitance 9,999 µF Accuracy ±(1% + 2) Best resolution 0.01 nF Frequency Maximum frequency 200 KHz Accuracy ±(0.005% + 1) Best resolution 0.01 Hz Duty cycle Maximum duty cycle 99.9% Accuracy within 2% per KHz + 0.1% Best resolution 0.1% Temperature measurement -200.0°C – 1090°C -328.0°F – 1994.0°F, 1.0% excluding probe 80 BK temperature probe -40 °C – 260°C -40 °F – 500°F, 2.2°C or 2% whichever is greater Conductance Maximum conductance 60.00 nS Accuracy ±(1.0% + 10) Maximum resolution 0.01 nS Operating range Operating temperature -20°C – 55°C Storage temperature -40°C – 60°C Physical 5.2 x 9.8x 20.1 cm (2.06 x 3.86 x 7.93 in) 624 g (22 oz.)
