HPE NW ION AP (RW) AP32

Lifecycle

• Obsolete Date 31-12-2099

Specifications

• Mounting Ceiling/Wall mount clip
• Input voltage PoE: 802.3bt (class 6) or 802.3at (class 4) DC power (12V)
• Certifications Wi-Fi Certified 6
• Warranty HPE Networking Instant On 2-Year
• Connectivity, standard Wi-Fi 11ax
• Power consumption 12.9W (PoE) 11.0W (DC)
• Wi-Fi antenna Dual Omnidirectional 2x2 MIMO
• Radio coverage Tri-band 802.11ax 2x2 6Ghz/5Ghz/2.4Ghz MU-MIMO
• Ports 1x 2.5GbE BaseT Uplink DC Power Connector LED status Indicators Reset/LED control button Kensington security slot

Quickspecs

• QuickSpecs (PDF)
• QuickSpecs (HTML)
• QuickSpecs
• QuickSpecs

Overview

The HPE Networking Instant On Access Point AP32 is a Wi-Fi CERTIFIED 6E™ wireless access point built to bring future-ready connectivity to small and medium businesses. The HPE Networking Instant On AP32 supports the new 6E wireless protocol that broadcasts on the 6GHz band, which is reserved for Wi-Fi 6E-enabled devices, and offers higher capacity and capability for the devices. This higher capacity needs a strong backhaul, so the HPE Networking Instant On AP32 comes with a 2.5GbE uplink port and PoE to make connectivity and power easy. With a 2x2 antenna array supporting 2 spatial streams, the HPE Networking Instant On AP32 provides robust connectivity for up to 75 devices and 2.8Gbps of wireless throughput. In the HPE Networking Instant On mobile app, choose to broadcast the 5GHz and 6GHz bands to achieve faster throughput speed, or switch to 2.4GHz and 6GHz for impressive range for modern laptops or smartphones.

What's new

• Keep your network protected with the HPE Networking Instant On Instant On mobile app or web portal, cloud-connected so you can manage or troubleshoot problems anywhere in the world.
• Wi-Fi CERTIFIED 6E™ support for up to 75 user devices.
• 2.5 gigabit Ethernet uplink port that relieves bottlenecks brought by bandwidth-intense applications.
• 6GHz band dedicated to Wi-Fi 6E-enabled devices with up to 2.4Gbps wireless throughput.
• The modern minimal design blends the HPE Networking Instant On AP32 into any environment. Enable quiet mode to disable lights for less distraction.

Features

802.11ax Wi-Fi Certified 6E

HPE Networking Instant On AP32 access points feature Orthogonal Frequency-Division Multiple Access (OFDMA), allowing multiple Wi-Fi 6 capable clients to be handled simultaneously per channel. This improves efficiency by boosting overall capacity, reducing latency, and improving end-user experience.

Target Wake Time (TWT) – Ideal for IoT devices that communicate infrequently, TWT establishes a schedule for when clients need to communicate with an AP. This reduces power consumption and can extend the battery life of clients.

Multiple Input, Multiple Output (MIMO) – Allows the access point to serve multiple clients (Wi-Fi 5 and Wi-Fi 6) simultaneously.

Use the HPE Networking Instant On mobile app or web portal to see where clients on your network are going with the application's insight.

Block certain types of traffic in the mobile app or web portal to keep your network safe and employees productive.

Wi-Fi 6E 6GHz Band to Fast-Track your Devices

HPE Networking Instant On Access Point AP32 is ready to elevate your growing network needs with Wi-Fi 6E.

This Tri-band, dual radio access point offers different broadcasting configurations: 6GHz and 5GHz for impressive throughput, 2.4GHz and 6GHz to support IoT and the most recent wireless devices, and 2.4GHz and 5GHz for businesses not yet ready to use the latest wireless standards.

Easily manage and update the HPE Networking Instant On AP32 band setting in the HPE Networking Instant On mobile app from anywhere.

Safeguard your Network with WPA-Enterprise Features

HPE Networking Instant On AP32 access points come with top-level security features, always on, out of the box, such as WPA2/WPA3 and Enhanced Open support for protecting your wireless network.
