Modul senzor curent MAX471 (m.877)
-
Ramburs cu Garantia de Livrare
Curierul special îți livrează produsul pe care tu îl achiți la primire. Dacă produsul nu este ca în descriere, îți recuperezi banii, inclusiv taxele de transport.
- Online
Descriere
Raporteaza produsVânzatorul este direct răspunzator pentru produsul afișat în această pagină.
Specificatii
Produsul este nou!
Produsul este la
fel cu cel prezentat in fotografii!
Specificații în limba engleză:
The current detection adopts the precision high end current detection amplifier chip MAX471 produced by American credit company.
The module needs no external power supply, and the inner module is directly used by the detected power supply.
The minimum operating current of MAX471 is 3V, and the minimum voltage input for this module is 3V.
Voltage detection is designed by using the principle of resistance partial pressure, which can reduce the input voltage of terminal interface by 5 times.
The maximum input voltage of Arduino is 5V, so the input voltage of the voltage detection module can not be greater than 5V * 5=25V (if the 3.3V system is used, the input voltage should not exceed 3.3Vx5=16.5V).
The test pin explains:
VT: voltage detection pin, the detected voltage is the input voltage of 1/5
AT: current detection pin
GND: and Arduino GND
VOUT/VIN: VOUT=VIN
Parameters:
The voltage detection range is 3-25V (Arduino working voltage is 5V) or 3-16.5V (Arduino working voltage is 3.3V);
current detection range: 0-3A, accuracy 200, current voltage conversion ratio 1V/A.
Example:
Using the Arduino to measure the input voltage and the working current of the load load, the Arduino working voltage is 5V.
• 1 bucată x modul senzor curent MAX471 (cod produs: m.877)
