Modul Wireless JBL WEM-1 - poze reale ! OKAZIE

Product Description

The JBL WEM-1 is a Wireless Expansion Module that allows you to make any loudspeaker (not included) wireless. Included is a transmitter that wirelessly transmits a signal up to 70 feet. The WEM-1 includes a receiver/amplifier that receives the wireless signal and drives any pair of loudspeakers with its internal 50-watt amplifier. The transmitter connects to the source using either line or speaker level inputs. The receiver/amplifier also offers equalization settings for several speakers. A local input allows you to hook up a portable device or gaming system to the amplifier. 2.4GHz technology - ensures high-performance sound up to 70 feet from transmitter 50-watt per channel digital amplifier Local input for your video game, iPod, or other portable music player Line- and speaker-level inputs Subwoofer output Frequency Range (+0, -1dB) - 20Hz - 20kHz S/N Ratio - 80dBA In the box - Owner's manual USA warranty sheet 1 x Receiver-amplifier module 1 x Power supply for receiver-amplifier 1 x 120V AC power cord for receiver-amplifier power supply Remote Control 2 x Wall-mount brackets for receiver 1 x Pedestal 1 x Transmitter module 1 x Power supply for transmitter 1 x 120V AC power cord for transmitter power supply 1 x 6' Audio stereo cable, RCA-RCA 1 x Wall-mount bracket for transmitter 2 x Panhead M3 x 4 machine screws 4 x Small, round, self-adhesive feet Unit Dimensions (H x W x D) - 1-1/8 x 6 x 3-7/8, Weight - 0.6 lb (Transmitter); 1-1/8 x 6-3/16 x 4-5/8, Weight - 0.9 lb (Receiver)

From the Manufacturer

JBL WEM-1 Wireless Expansion Module: Enjoy Music Anywhere, Wirelessly

The JBL WEM-1 is a Wireless Expansion Module that allows the user to make any loudspeaker wireless. The kit contains a transmitter that wirelessly transmits a signal up to 70 feet. The WEM-1 includes a receiver/amplifier that receives the wireless signal and drives any pair of loudspeakers with its internal 50 watt amplifier. The transmitter connects to the source using either line or speaker level inputs. The receiver/amplfiier also offers equalization settings for several speakers. A local input allows the user to hook up a portable device or gaming system to the amplifiier.

What Does the WEM-1 Do?

Turn any speaker into a wireless music receiver

The WEM-1 eliminates the need to run speaker wires across a room or through walls, allowing you to transmit music throughout your home easily. Plus, it can connect to virtually any pair of speakers you already own, or would like to own. How cool is that! The system includes a transmitter unit that connects to your audio source and a receiver with built-in amplifier that you connect to your speakers. It is just that easy. The system includes a wireless remote control allowing you to control volume from a remote location. Plus, the WEM-1 has a local input, allowing you to connect an additional audio source such as a game console or portable audio player at the remote location.

Here are just a few applications for the WEM-1 that can enhance the enjoyment of music in your home:

• Add surround speakers to your home theater system without the trouble and expense of running speaker wires across the room
• Add speakers to any room in your home up to 70 feet away. Put music in your workshop, garage, playroom, living room, den, and kitchen or laundry room by simply adding a pair of speakers.
• Connect your computer to speakers in a second location to enjoy music while surfing the web or working.
• Enjoy music from your iPod in a remote location such as your bedroom or kitchen.

2.4 GHz Technology Yields Multiple Zone Possibilities with Simple Setup

In the unlikely event of interference, or if you wish to use multiple WEM-1 transmitters and receivers, you can change the channel in which the system operates by setting the four-position ID code selector found on both the transmitter and receiver. If you or a family member is using the local input for a gaming console or portable music player in their location, having selected a unique ID code for that location will allow you to enjoy a different source from other locations.

The receiver's 50-Watt-per-channel digital amplifier delivers the horsepower you need for great audio playback on connected speakers, while the 2.4GHz antenna ensures high-performance sound up to 70 feet from the transmitter. Local input allow connection of gaming consoles, iPods or other portable music players, and line-level and speaker-level inputs allow easy connection to home receivers, portable music players, computers, CD players and much more.

The WEM-1’s Transmitter and receiver/amplifier may be mounted horizontally, vertically or on the wall. Wire-management and vertical stand are included for easy installation and placement of the receiver/amplifier. Wall brackets are included for both the transmitter and receiver modules, providing further expansion of the installation possibilities.
