SOCOMEC ITYS 1000VA VFI UPS 1/1 PF=1 WI

SOCOMEC ITYS 1000VA VFI UPS 1/1 PF=1 WITH BATTERY INTEGRATED

- Embedded dry-contact interface.
- Input mains switch breaker.
- Connection for battery extension modules.
- Power off the UPS remotely.
- Internal temperature sensor.

Input connection C14
Number of output connections C13 4 pcs

• Input operation voltage (max): 300 V
• Output operation voltage (max): 240 V
• Output frequency: 50/60 Hz
• Number of input phases: 1
• Number of output phases: 1
• UPS topology: Double-conversion (Online)
• RS-232 ports: 1
• AC outlet types: C13 coupler
• Power plug: C14 coupler
• USB port type: USB Type-B
• Emergency Power Off (EPO): Yes
• Output operation voltage (min): 200 V
• Efficiency: 93%
• Input power factor: 0.99
• Waveform: Sine
• ECO mode: Yes
• Efficiency (ECO mode): 98%
• Safety: IEC/EN 62040-1, AS 62040.1.1, AS 62040.1.2
• Output power capacity: 1 kVA
• AC outlets quantity: 4 AC outlet(s)
• Output power: 1000 W
• Input frequency: 40 - 70 Hz
• Crest factor: 3:1
• Output power factor: 1
• Input operation voltage (min): 160 V
• Power protection features: Short circuit
• Charging current: 8 A
• Operating altitude: 0 - 1000 m
• Typical backup time at full load: 7.8 min
• Battery capacity: 7 Ah
• Form Factor: Mini Tower
