Controler MPPT

Controler Conext mppt 60A 150VIP degree of protection IP20
Product weight 4.8 kg (10.8 lb)
Shipping weight 8.0 kg (17.6 lb)
Product dimensions (H x W x D) 36.8 x 14.6 x 13.8 cm (14.5 × 5.8 × 5.5 in)
Shipping dimensions (H x W x D) 48.3 x 22.9 x 35 cm (19.0 × 9.0 × 9.8 in)
Device mounting Vertical wall mount
Ambient air temperature for operation -20 °C to 45 °C (-4 °F to 113 °F)
Storage temperature range -40 °C to 85 °C (-40 °F to 185 °F) full power, power derating above 45 °C
Operating altitude Sea level to 2000 m (6562 ft)
System network and remote monitoring Available with Insight Energy Management
Warranty Please refer to our website, SEsolar.com for the latest version of the warranty statement. Part number 865-1030-1
Features
Display type LCD, 2 lines 16 digits
Regulatory approvals
Safety CSA certified (UL1741, CSA 107.1) and CE marked for the Low-voltage Directive (EN50178) EMC FCC and Industry Canada (Class B), CE marked for the EMC Directive (EN61000-6-1, -6-3), C-Tick compliant Compatible products part numbers
Conext XW Pro XW Pro 6848 120/240 VAC (865-6848-21), XW Pro 8548 230 VAC (865-8548-55) Conext XW+ XW+ 6848 120/240 VAC (865-6848-01), XW+ 8548 230 VAC (855-8548-61)
Conext SW IEC (230 V) SW 4024: 865-4024-55 / SW 4048: 865-4048-55
Conext SW UL (120 V) SW 4024: 865-4024-21 / SW 4048: 865-4048-21
Conext XW Power Distribution Panels For XW+ 230V: 865-1014-01 / For XW Pro and XW+ 120/240V: 865-1015-01
Conext XW Mini Power Distribution Panels 865‑1013-01
Conext SW Power Distribution Panels SW DC Distribution Panel: 865‑1016 / SW AC Distribution Panel (230V): 865-1017-61 / SW AC Distribution Panel (120/240V): 865-1017
MPPT Disconnect RS / RS Initiator Switch 865-1036 / 865-1039
Conext Automatic Generator Start 865-1060-01
Conext Battery Monitor 865‑1080-01
Conext Quick Fit for North America XW Pro + L: 865-6848-21LPS / XW+ H: 865-6848-01LPS / SW 4048: 865-4048LPS / SW 4024: 865-4024LPS Specifications are subject to change without notice.
Schneider Electric Solar
solar.se.com
Head Office Spain Office
#100 – 13091 Vanier Avenida de Tenerife 4
Place, Richmond, BC San Sebastian de los Reyes
V6V 2J1, Canada 28703 Madrid
© 2022 Schneider Electric. All Rights Reserved. Schneider Electric | Life Is On is a trademark and the property of Schneider
Electric SE, its subsidiaries, and affiliated companies.DS20220511 - Conext MPPT 60 150.indd
